Cr20Ni30 Resistance Wire for Efficient Hydrogen Generation in Electrolysis

Cr20Ni30 Resistance Wire for Efficient Hydrogen Generation in Electrolysis

Наименование марки:	DLX
Номер модели:	Нихромовая проволока Кр20Н30
МОК:	10 кг
Условия оплаты:	Л/К, Д/А, Д/П, Т/Т, западное соединение
Способность к поставкам:	500 тонн в месяц

Подробная информация

Характер продукции

Подробная информация

Место происхождения:

Китай, Цзянсу

Сертификация:

Ce,Rohs

Поставка способности:

500 тонн в месяц

Выделить:

Cr20Ni30 resistance wire for electrolysis

hydrogen generation resistance wire

high-efficiency electrolysis resistance wire

Характер продукции

Cr20Ni30 Resistance Wire for Efficient Hydrogen Generation in Electrolysis

The global push for clean and sustainable energy has brought hydrogen to the forefront of industrial applications, with electrolytic hydrogen production being a key method for obtaining hydrogen without carbon emissions. As industries move towards more eco-friendly solutions, selecting the right materials for electrolyzers becomes critical. DLX's Cr20Ni30 Resistance Wire offers a highly effective solution for efficient hydrogen generation in electrolysis, combining durability, high resistance, and excellent performance under harsh conditions.

Product Overview

DLX's Cr20Ni30 Resistance Wire is a high-performance alloy wire designed specifically for industrial electrolyzers that produce hydrogen via electrolysis. Composed of 20% chromium and 30% nickel, this wire offers an ideal balance between electrical resistance and thermal stability, making it perfect for use in electrolyzers that require consistent and reliable performance in high-temperature, high-corrosion environments.

When used in electrolytic hydrogen production, Cr20Ni30 Resistance Wire helps minimize energy loss, improve the efficiency of the electrolysis process, and extend the lifespan of the equipment, ultimately reducing operational costs for industries.

Performance / material	Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Ni	90	Rest	Rest	55.0~61.0	34.0~37.0	30.0~34.0
Cr	10	20.0~23.0	28.0~31.0	28.0~31.0	18.0~21.0	18.0~21.0
Fe	--	≤1.0	≤1.0	Rest	Rest	Rest
Maximum temperature℃	1300	1200	1250	1150	1100	1100
Melting point ℃	1400	1400	1380	1390	1390	1390
Density g/cm³	8.7	8.4	8.1	8.2	7.9	7.9
Resistivity at 20℃ (μΩ*m)	--	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
Elongation at rupture	≥20	≥20	≥20	≥20	≥20	≥20
Specific heat (J/g.℃)	--	0.44	0.461	0.494	0.5	0.5
Thermal conductivity (KJ/m.h℃)	--	60.3	45.2	45.2	43.8	43.8
Coefficient of linear expansion a×10⁻⁶/(20~1000℃)	--	18	17	17	19	19
Micrographic structure	--	Austenite	Austenite	Austenite	Austenite	Austenite
Magnetic properties	--	Non-magnetic	Non-magnetic	Non-magnetic	Weak magnetic	Weak magnetic

Shape	Size (mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)×(0.5-6.0)
Strip	(0.5-2.5)×(5-40)

Key Features & Benefits

Excellent Corrosion Resistance
The Cr20Ni30 wire has exceptional resistance to oxidation and corrosion, even at high temperatures. This allows for extended service life in electrolyzers, where other materials may degrade quickly due to constant exposure to harsh chemicals and high heat.
High Electrical Resistance
Cr20Ni30's high electrical resistance ensures minimal energy loss during the electrolysis process, enhancing the efficiency of hydrogen production and making it a reliable choice for high-performance electrolyzers.
Superior Thermal Stability
This wire can withstand temperatures up to 1200°C, allowing it to function efficiently even in high-temperature environments, which is critical for continuous electrolysis operations.
Durability in Harsh Conditions
The combination of strength, corrosion resistance, and high temperature tolerance means this wire can endure the challenging conditions of industrial electrolysis for extended periods without degradation.
Customizable Options
DLX offers various diameters and packaging options to meet the specific requirements of your application. Whether you need fine wire for small electrolysis cells or thicker wire for larger systems, we can provide the ideal solution.

Advantages of DLX's Cr20Ni30 Resistance Wire

At DLX, we pride ourselves on offering high-quality products designed to meet the demanding needs of the electrolytic hydrogen production industry. While there are other resistance wires available, DLX's Cr20Ni30 wire sets itself apart due to several key advantages:

Consistent Quality: DLX ensures that every batch of wire is thoroughly tested for quality and performance, providing customers with a product they can rely on, every time.
Cost-Effective Long-Term Solution: While the initial investment might be higher than some alternatives, the wire's longevity, reduced maintenance requirements, and higher efficiency mean significant cost savings over time.
Customer-Focused Service: We offer personalized support, working closely with clients to understand their specific needs and offering custom solutions to optimize their electrolysis systems.
Global Availability: With a well-established global distribution network, DLX ensures that Cr20Ni30 resistance wire is available to customers around the world, making it an ideal choice for industries with international operations.

Applications

The Cr20Ni30 Resistance Wire is versatile and finds applications across multiple industries, including:

Electrolytic Hydrogen Production: The wire is crucial in the production of green hydrogen through water electrolysis, contributing to the efficiency and effectiveness of electrolyzers.
Industrial Heating Elements: Cr20Ni30 resistance wire is widely used in high-temperature applications such as industrial heating elements for furnaces, ovens, and heat treatment processes.
Metal Extraction: This wire is also used in applications requiring high resistance materials for electrochemical processes, including metal extraction and refining.
Thermal Management: The wire's high-temperature tolerance makes it suitable for applications in thermal management systems, ensuring consistent performance in extreme environments.

Industry Analysis

The electrolytic hydrogen production industry is growing rapidly, with a focus on making hydrogen generation more efficient and cost-effective. As industries move towards cleaner energy alternatives, the demand for green hydrogen has skyrocketed. Electrolyzers are at the heart of this process, and as a result, high-performance materials like Cr20Ni30 resistance wire are becoming increasingly vital.

Key challenges in the industry include minimizing energy consumption, reducing maintenance, and ensuring long-term durability of the electrolysis equipment. Materials such as Cr20Ni30 are ideal because they address all of these issues, ensuring that electrolyzers operate efficiently with minimal downtime.

In the coming years, the global market for electrolytic hydrogen production is expected to grow significantly, driven by the need for clean energy solutions and advancements in electrolysis technology. This growth will increase the demand for high-quality materials like Cr20Ni30 resistance wire, positioning DLX as a leader in providing high-performance solutions for the hydrogen economy.

Frequently Asked Questions

Why is Cr20Ni30 Resistance Wire ideal for electrolytic hydrogen production?

Cr20Ni30 wire offers excellent corrosion resistance, high thermal stability, and optimal electrical resistance, making it perfect for the demanding conditions of electrolyzers used in hydrogen production.

Can Cr20Ni30 wire be used in other applications?

Yes, Cr20Ni30 wire is also used in heating elements, industrial furnaces, and metal extraction, making it a versatile solution for a wide range of industries.

How does Cr20Ni30 wire improve the efficiency of electrolysis?

The wire's high electrical resistance helps reduce energy losses during electrolysis, making the hydrogen production process more efficient.

Is Cr20Ni30 wire customizable for different needs?

Absolutely. DLX offers a range of wire diameters and can provide custom solutions to meet the specific needs of each application.

What are the temperature limits for Cr20Ni30 Resistance Wire?

Cr20Ni30 wire can withstand temperatures up to 1200°C, ensuring reliability even in high-temperature environments like electrolyzers.

How long does Cr20Ni30 wire last in electrolytic applications?

The wire's durability, coupled with its corrosion resistance, ensures a long operational life, reducing the frequency of maintenance and replacement.

How does Cr20Ni30 wire compare to other materials in terms of cost?

While it may have a higher initial cost, the wire's long-term durability, reduced maintenance costs, and increased efficiency make it a cost-effective solution in the long run.

What industries benefit most from Cr20Ni30 wire?

Industries involved in hydrogen production, high-temperature applications, and electrochemical processes will find Cr20Ni30 wire particularly beneficial.
